Working height: 23 Meter
Working outreach: 11.63  Meter
Capacity: 200 Kg

• Horizontal Working Outreach* 11.63 m
• Platform capacity – unrestricted /120 kg
• Platform capacity – restricted /200 kg
• Up & Over Height* 9.38 m
• Swing (non continuous) 360°
• Jib – overall length 1.43 m
• Jib – range of articulation (+/-) 85° (-1° / -86°)
• Platform size (standard 2 persons) 0.69 m x 1.34 m
• Stowed width (with std. 2P platform) 1.34 m
• Dimensions:
A. Stowed width (without platform) 1 0.99 m
B. Stowed height (on tracks) 2 1.99 m
C. Stowed length (on tracks) 6 m
D. Outrigger footprint 3.98 m x 3.98 m
• Machine weight (with standard platform) 3 3,090 kg
• Max. ground bearing pressure (on outriggers) 3.06 kg/cm2
• Maximum drive speed (single speed m/c) Petrol 1 km/h
• Gradeability 28.7%
• Maximum operating slope 13°
• Max. Approach / Depart angles Front 22° / Rear 25°
• Width of Undercarriage (Retracted/Extended) 0.99 m / 1.29 m
• Basket rotation 124° (+/-62°)
